Electric Floor Heating Cable UTH

underfloor heating cable thin 3.6mm
flexible electric underfloor heating cable loose

Electric Floor Heating Cable UTH

 Our Electric Floor Heating Cable UTH just increase a 3.6mm height in floor and it is with twin conductor.

  • Cable construction :

    Twin conductor

  • Twin conductor :

    Solid heating core

  • Insulation :

    Fluoroplastic

  • Protective jacket :

    PVC

  • Connector :

    Out splice

  • Outside diameter :

    3.6mm

  • Rated voltage :

    220V-240V

  • Liner power :

    12W/m or 15W/m

  • Resistance tolerance :

    +10%/-5%
Inquire Now

The Electric Floor Heating Cable UTH can be used for ceramic tiles , natural stone and wooden floor etc. It's also suitable for either primary or secondary heat.



Technical Data:

Part NO. Wattage (w) Length(m) Resistance(Ω)
UTH-CABLE12-150 150 12.5 322.67
UTH-CABLE12-225 225 18.8 215.11
UTH-CABLE12-300 300 25 161.33
UTH-CABLE12-375 375 31.3 129.07
UTH-CABLE12-450 450 37.5 107.56
UTH-CABLE12-525 525 43.8 92.19
UTH-CABLE12-600 600 50 56.94
UTH-CABLE12-750 1000 62.5 80.67
UTH-CABLE12-900 900 75 53.78
UTH-CABLE12-1050 1050 87.5 46.10
UTH-CABLE12-1200 1200 100 40.33
UTH-CABLE12-1500 1500 125 32.27
UTH-CABLE12-1800 1800 150 26.89





We can provide customized production services according to your needs. The diameter and material of the cable can be customized according to your requirements.





Hot Tags : electric underfloor heating 12W OEM floor heating cables wholesale OEM under tile floor heating OEM factory underfloor heating 12W power customized in-screed floor heaing cable flexible reliable under tile floor heating custom
